Запайщик лотков TURBOVAC TPS COMPACT XL

The tray sealer TPS COMPACT XL moreover, the required amount is used in the food industry and catering for sealing of polymer film containers with preliminary degassing and subsequent gazonapolnennye. When using this device to achieve a higher degree of vacuum, which prolongs the shelf-life of food products. The body is made of stainless steel AISI 304.

Features:

• The intuitive control panel interface
• Change sets tooling, matrix can be easily changed without requiring special tools
• The function of packaging in a modified environment
• Trim the film around the perimeter of the containers
• Requires connection to compressed air

Features:

• Capacity: from 3 to 5 cycles/min.
• Proizvoditelnosti pump: 21 m3/h
• Cycle time: 25-30 sec.
• Air consumption: 20 l/min.
• The air pressure in the pneumatic system: 6 Bar
• Voltage: 380 V
• Rated power: 1.5 kW
• Strap length: 400 mm
• Maximum container dimensions: mm 395x290
• Maximum container height: 120mm
• Maximum film width: 420 mm
• Maximum diameter of film rolls: 250 mm
• The work surface height of 850 mm
• Dimensions: mm HH
• Weight: 150 kg

Accessories (to be ordered separately):

• The vacuum pump (Busch 21 m3) with oxygen (when using gas mixtures with high oxygen content of over 21%)
• Vacuum pump capacity: 40 m3 (Busch) (not compatible with internal compressor)
• Weighing tables
• System of rewinding of the film (automates the process of removing residue of the film after the end of the cycle through its winding to the driven reels in the basic configuration removal is done manually)
• Liquid filter (protects the pump from ingress of moisture when packaging soups, sauces, meat in marinade, etc.)
